Supermarine Spitfire PR Mk XIII prototype L1004

The Supermarine Spitfire PR Mk XIII was a low-level photo-reconnaissance aircraft adapted from earlier Spitfire designs.

Key Specifications of the PR Mk XIII:

  • Designation: PR Mk XIII
  • Type Number: 367
  • First Flight: August 1942 (L1004)
  • Service Entry: April 1943
  • Type: Low-level Photo-Reconnaissance Aircraft
  • Span: 36 ft 10 in (11.23 m)
  • Length: 29 ft 11 in (9.12 m)
  • Height: 11 ft 5½ in (3.49 m) [Tail Up]
  • Engine: Single-speed, single-stage 1,645 hp (1,227 kW) Merlin 32
  • Weight:
    • Empty: 5,085 lb (2,307 kg)
    • Maximum Loaded: 6,500 lb (2,948 kg)
  • Max Speed: 345 mph (555 km/h) at 10,000 ft (3,050 m)
  • Service Ceiling: 37,000 ft (11,280 m)
  • Range: 700 miles (1,126 km)
  • Armament:
    • Four 0.303 in (7.7 mm) Browning machine guns
  • Cockpit: Unpressurized, fitted with internal bulletproof glass for pilot protection.
  • Tailwheel: Fixed
  • Camera Equipment:
    • Two vertical F.24 cameras
    • One oblique F.24 camera, ideal for reconnaissance photography.
  • Propeller: de Havilland, three-blade, constant-speed, variable-pitch Type 5/39.
  • Radio Equipment: TR.1133
  • Production: 18 aircraft were produced as conversions from earlier Spitfire models.
